Using state-of-the-art induction heating technology, the test medium quickly reaches the required temperature within 3-5 minutes reducing unproductive waiting times to a minimum. Because the heating process occurs directly inside the beaker rather than by applying heat from the outside, the DisiTest 50 ensures very precise and homogeneous temperature control.
Because the test medium temperature is permanently measured - also before starting a test - no manual check of nominal temperature is needed. Tests start automatically when the required temperature has been reached.
Advanced Detection Technology
The DisiTest 50 automatically detects and records:
Temperature of test medium
Individual tablet disintegration time
Beaker filling level
Test medium type (e.g. water/buffer or 0.1 N HCl)
Serial number of basket used
From test setup to cleaning – the DisiTest 50 sets new standards for fast and ergonomic handling. Wireless baskets with self-centering magnetic coupling can be conveniently exchanged within seconds and cleaning has never been easier. To ensure a long product life, the robust baskets are sealed and protected against corrosion.
Wireless baskets without any cables
Self-centering magnetic coupling
Robust basket design, protected against corrosion
Quick-change tubes for fast industrial cleaning
User-friendly Touch Screen Operation
The DisiTest 50 is controlled via an intuitive and clearly structured color touch screen. Additional PC software is not required. Once a test has been started, the current disintegration status of each tablet is displayed graphically. Different testing modes guarantee fast test setup with programmed products and/or methods including T1/T2 limits – or alternatively allow performing direct tests without any programming. Different access levels ensure that data can be modified only by authorized personnel.
Graphical display of disintegration status per tube
Temperature and time
Pre-testing procedure possible
Programming of up to 100 products/methods
Integrated calibration & verification functions
Direct printing of statistical reports
Upon completion of a test, a report with measured results, statistics and temperature protocol is automatically printed.
The DisiTest 50 can be extended to a fully automatic disintegration testing system with up to 4 independent stations - all controlled via the touch screen of the Master station. Because individual testing stations are connected using TCP/IP technology, system layout is flexible and retrofitting additional stations is possible anytime.
To completely eliminate waiting times, use the optional MediaPrep station to pre-heat test media for maximum efficiency. Particularly useful when pre-testing is required.
1 – 4 (independent)
Strokes per minute Frequency
Strokes per minute Accuracy
55 mm (2.17 inch)
Stroke height Accuracy
+/- 2 mm (0.08 inch)
Temperature Range (programmable)
25 – 40°C
Temperature Measuring accuracy
up to 100 products / methods
PostScript® network printer (LAN), serial printer
50 Watt / 3 A
110 – 240 V, 50 – 60 Hz
The DisiTest 50 fully complies with all CE and EMC equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
